Quick Bga Rework Station
The DH-G600 is a professional smd bga rework station designed for precision repair of modern electronics. It combines a smart touchscreen interface with a triple-zone heating system and closed-loop temperature control (±2°C accuracy) to ensure perfect, repeatable results.
Description
DH-G600 Advanced BGA & SMT Rework Station
Professional Precision for Demanding Electronics Repair
The DH-G600 is a state-of-the-art smd bga rework station engineered to deliver unmatched accuracy, repeatability, and control in PCB repair. Integrating a smart digital vision alignment system with triple-zone independent heating and closed-loop temperature control, it is the ultimate solution for repairing high-density assemblies found in modern consumer electronics. This station is specifically designed as part of a comprehensive suite of phone repair tools, enabling technicians to tackle complex BGA, QFN, and CSP rework with confidence. Its automated processes and intelligent features make it an indispensable mobile repairing tool and machines for any serious repair center, R&D facility, or production line requiring reliable rework capabilities.
Product Details & Specifications
Core Technology & Control System
1.Smart Touch Interface & Data Management: Features a high-definition touchscreen HMI for intuitive control. It enables real-time graphing and instant analysis of set vs. actual temperature curves, allowing for on-the-fly corrections. With a USB port, all profiles and curve data can be exported for documentation and analysis.
2.Precision Temperature Management: Utilizes high-accuracy K-type thermocouples in a closed-loop system with automatic compensation to maintain a tight temperature deviation within ±2°C. Four external sensor ports allow for meticulous verification directly on the PCB.
3.Advanced Vision Alignment: Employs a high-precision digital video alignment system combined with a V-slot base and a linear slide mechanism. This allows for fine micro-adjustments or rapid positioning in X, Y, and R axes, accommodating various PCB layouts and sizes with pinpoint accuracy.
Heating, Cooling & Process Automation
1.Three-Zone Independent Heating: The top, bottom, and preheat zones operate independently, each capable of multi-segment temperature control (up to 8 segments per zone) to synchronize perfectly for optimal soldering results.
2.PID Algorithm & Profile Storage: Each heating zone uses an independent PID algorithm for uniform heating and accurate temperature ramps. The system can store a vast library of temperature curves, which can be easily recalled, analyzed, and modified directly on the touchscreen.
3.Intelligent Cooling System: A high-power cross-flow fan provides rapid cooling after heating cycles to prevent PCB warping. The cooling system activates automatically when heating stops and shuts off once ambient temperature is reached, protecting the machine from thermal aging.
4.Voice Alert & Automated Process: Configurable voice alerts notify operators 5-10 seconds before process completion. The entire sequence-heating, soaking, cooling-can be automated for consistent, hands-free operation.
Design, Safety & Compatibility
1.Universal Fixturing & Protection: A flexible, movable universal fixture securely holds PCBs, protecting edge components and preventing board deformation during rework, adaptable to various BGA package sizes.
2.360° Rotatable Alloy Nozzles: Comes with multiple spec alloy nozzles that can rotate 360° for easy positioning, installation, and replacement to suit different component footprints.
3.Safety & Certification: CE certified for safety. Includes emergency stop switch and automatic power-cut protection in case of system malfunction, ensuring a safe working environment.
Products Parameters
| Parameter | Specification |
|---|---|
| Model | DH-G600 |
| Temperature Control | Closed-loop with K-Type Thermocouple |
| Temperature Accuracy | ±2°C |
| Heating Zones | 3 (Top, Bottom, Preheat) |
| Temperature Segments | 8 segments per upper/lower zone |
| Profile Storage | Extensive Onboard Library |
| Alignment System | Digital Video + Laser & V-Slot |
| Positioning | X, Y, R-axis Fine Adjustment |
| Cooling | Automatic High-Power Cross-Flow Fan |
| Data Port | USB for Data Export & Peripheral Connection |
| Safety | CE Certified, Emergency Stop, Auto Power-Off |
Why the DH-G600 is the Ideal Choice
The DH-5880 transcends being a simple tool; it is a complete, intelligent rework solution. It consolidates the precision required for modern micro-soldering with the robustness needed for daily use. By choosing this professional smd bga rework station, you invest in a core mobile repairing tool and machines that elevates repair quality, increases first-pass success rates, and streamlines technician workflow. It is the definitive answer for anyone seeking reliable, high-end phone repair tools capable of handling the most challenging board-level repairs with ease and consistency.
