LED TV Panel Repair
LED TV panel repair machine which can be used for Sony, Samsung and LG LED TV panel replacement,also desoldering and soldering other components, for instance, BGA,POP,QFN and some others small to 0.5*0.25mm.
Description
DH-G760 LED TV panel repair
1. The main parameters
| Power supply | 110~250V 50/60Hz |
| power/power plug | 5200W/optional(USA,EU,Indian and Africa etc.) |
| LED fixture | special design for LED chips picking up |
| Min LED chip size | 0201 |
| IR preheating zone | anti-high-temperature glass-shield which stop LED from dropping inside |
| Temperature controlling system | K-type, closed-loop |
| Motor | serve and PLC |
| Dimension | 670*800*700mm |
| Net weight | 80kg |
2. The purpose of LED TV panel repair
This is backlights of television, the fluorescent lamps have a diameter 2mm
TV backlights LED modules LED strips
All of them can be reworked or replaced on the rework station DH-G760, for the LED strips,
there is a special jig for the strips conveyed as below:
The fixture in the red circle consists of two parts
The special fixture is automatic running with that optical CCD camera, the right part for LED placed,
there can be put one real of led chips there one time, and the machines top head can automatically pick
up a LED chip there for aligning.
3. For other chip BGA, POP and QFN .etc, repairing
Chips
These chip as above are some of them which can be reworked, also, they can be automatical removal,
solder, pick up and replace, etc.
4. The machine's main parts
Monitor screen optical CCD
X/Y movable imported PLC
FQA for the LED TV panel repairing:
Q: Does the LED have a direction when putting on an LED module?
A: Yes, just make your LED strip fixed on that special fixture, its direction is always right.
Q: Do I need to use flux paste when soldering?
A: According to the real experience, we suggest you brush a little on pads of LED mainboard.
3. Q: When desoldering the bad LED chips from the mainboard, if those LED chips around that bad one
will be heating up?
A: There would be customized an upper nozzle with a small size, such as, 10*10mm for you using,
which will make those LED lights be able to be protected from heating over.
4.Q: do you sell any components about LED?
A: We are a leading manufacturer of LED rework station and automated equipment only.
