BGA Rework Station For Laptop Motherboard

                                                      BGA Rework Station for laptop motherboard

A BGA rework station is a specialized tool used to repair laptop motherboards. It is a device used to remove

and replace integrated circuits (ICs) and Ball Grid Array (BGA) chips on a laptop motherboard. The BGA rework

 station can be used to repair damaged components on the motherboard or replace an obsolete or damaged IC or

 BGA chip. The rework station uses hot air to heat up components, designed specifically for the laptop motherboard

 which is being worked on, making sure the device functions properly again. A rework station is also used to create

electrical connections between the motherboard board and components, as well as for diagnostic testing.

1.Application Of BGA Rework Station for laptop motherboard

Suitable for different PCB.

The motherboard of a computer, smartphone, laptop, MacBook logic board, digital camera, air conditioner,

TV and other electronic equipment from the medical industry, communication industry, automobile industry, etc.

Suitable for different kind of chips: BGA,PGA,POP,BQFP,QFN,SOT223,PLCC,TQFP,TDFN,TSOP, PBGA,CPGA,LED chip.

2.Product Features of BGA Rework Station for laptop motherboard

• Desoldering, mounting and soldering automatically.

• Characteristic of high volume (250 l/min), low pressure (0.22kg/ cm2), low temp (220°C) rework completely

guarantees BGA chips electricity and excellent soldering quality.

•Utilization of silent and low-pressure type air blower permits the regulation of silent ventilator, the airflow can

 be regulated to 250 l/Min the maximum.

•Hot air multi-hole round center support is especially useful for big-size PCB and BGA located in the center of PCB.

Avoid cold soldering and IC-drop situation.

•The temperature profile of the bottom hot air heater can reach as high as 300°C, critical for big size motherboard.

Meanwhile, the upper heater could be set as synchronized or independent work.

3.Specification of BGA Rework Station for laptop motherboard

4.Details of BGA Rework Station for laptop motherboard

5. Why Choose Our BGA Rework Station for laptop motherboard?

6.Certificate of BGA Rework Station for laptop motherboard

To offer quality products, SHENZHEN DINGHUA TECHNOLOGY DEVELOPMENT CO., LTD was the first to pass

UL, E-MARK, CCC, FCC, CE ROHS certificates. Meanwhile, to improve and perfect the quality system, Dinghua has

passed ISO, GMP, FCCA, C-TPAT on-site audit certification.

7.Packing & Shipment of BGA Rework Station for laptop motherboard

8.Contcact

Email: john@dh-kc.com

WhatsApp/Wechat:+86 157 6811 4827
