Ir Rework Station Reflow Station

1. With serve motor to support optical CCD automatically running
2. Automaitc chip-feeder used for chips 1*1~55*55mm
3. Movable IR preheating area, +/-10mm
4. Double-joysticks for better users' experience

Send Inquiry

Description

DH-A4D Automatic Optical Alignment

Specification

Total Power	6800W
Top heater	1200W
Bottom heater	2nd 1200W, 3rd German IR infrared heater 4200W
Voltage	AC220V/110V ±10％ 50Hz/60Hz
Operation mode	Double joysticks operation. Fully automatic positioning, soldering, cooling, integration.
Optical CCD camera lense	Automatic Frontward / backward, right / left, or manual by joysticks
Camera magnification	2.0 million pixels(Digital zoom 10X-180X times)
Workbench fine-tuning:	±15mm forward/backward, ±15mm right/left
BGA positioning	Laser position, fast and accurate position of PCB and BGA
Top airspeed	Can be adjusted by adjusting knob, prevent tiny BGA from movement.
PCB Positioning	Intelligent positioning, PCB can be adjusted in X, Y-direction with "5 points support" + V-groove PCB bracket + universal fixtures.
Temperature control	K sensor, close loop, PLC control, Servo driver
Placement accuracy:	±0.01mm
Temp accuracy	±1℃
Lighting	Taiwan led working light, any angle adjustable
Temperature profile storage	50000 groups
PCB size	Max 500×420 mm Min 22×22 mm
BGA chip	1x1 - 80x80 mm
Minimum chip spacing	0.1mm
External temper sensor	4pc
Dimension	790x60x950mm
Net weight	95KG
