Product Discription Dinghua SMT X-ray Inspection Machine DH-X8 for Electronics Manufacturer Solder Voids Cracks Bridges and Other Defects Detection. As professional inspection systems, the pcb xray inspector adopts X-ray technology to check internal flaws and abnormal conditions inside objects...
Description
Product Discription
Dinghua SMT X-ray Inspection Machine DH-X8 for Electronics Manufacturer Solder Voids Cracks Bridges and Other Defects Detection.
As professional inspection systems, the pcb xray inspector adopts X-ray technology to check internal flaws and abnormal conditions inside objects and materials. This solution is widely applied in manufacturing, aviation and medical industries.
In electronics production, this professional xray machine for pcb bords is specially used to detect welding joints, castings and electronic components, covering common defects like cracks, voids and inclusions.
Features:
* Equipped with imported enclosed X-ray tube, the core configuration of this pcb xray inspector supports 90KV, with 130KV optional.
* High-resolution structural design delivers optimal imaging effect within a very short time.
* The loading platform size is 580mm * 570mm, with load capacity up to 10-20KG, perfectly matching the use demand of xray machine for pcb bords.
* Support cursor navigation positioning, allowing fast selection of shooting position.
* Built-in laser automatic navigation and positioning, greatly improving detection efficiency.
* Inclined multi-angle detection makes it easier to detect sample defects,The light tube flat plate can rotate
* (+/-60 °), making the detection image clearer and more intuitive.
Product Specification
|
Whole machine status
|
||||
|
Dimension
|
1500 *1500 *2100mm
|
|
Power supply
|
AC220V 10A
|
|
Weight
|
Approx 1500KG
|
Gross weight
|
Approx 2089KG
|
|
|
Wooden box
|
1940 ×1740 ×2280mm
|
Rated power
|
1.7KW
|
|
|
Door-opened
|
Manual+system induction
|
Inspection mode
|
off-line
|
|
|
Loading way
|
Human-being
|
Authority management
|
password
|
|
|
X-ray light tube
|
||||
|
Light tube type
|
sealed type
|
|
Light tube current
|
200ɥA
|
|
Light tube voltage
|
130KV
|
focal spot size
|
5um
|
|
|
cooling-down method
|
Forced air cooling
|
Geometry magnification
|
200 times
|
|
|
Industrial personal Computer
|
||||
|
Display
|
24-inch HD monitor
|
|
Operating system
|
Windows10 64
|
|
Operate mode
|
Keyboard / mouse
|
Hard disk / memory
|
1TB/8G
|
|
|
CPU
|
i5 +8400
|
Brand
|
Dinghua Technology(own)
|
|
Product Application
