Bga Inspection



The Dinghua DH-X8 is a professional electronics xray bga inspection system built for reliable non-destructive testing. As a high-performance x ray machine pcb, it delivers clear, high-resolution imaging to detect hidden defects in PCBs and electronic components. This stable xray bga solution is widely used in SMT production, quality control, and electronics repair to improve product yield and ensure assembly reliability.



The DH-X8 electronics xray bga inspection machine uses a 130KV closed-type X-ray tube that offers long service life and almost no maintenance, making it suitable for continuous daily use. Its new-generation high-definition digital flat-panel detector captures sharp images quickly, helping operators identify defects efficiently. This x ray machine pcb supports precise X/Y/Z axis movement and laser auto-navigation, allowing users to locate and lock inspection targets in seconds.



Designed for versatility, the DH-X8 xray bga equipment supports ±60° tilt viewing and optional 360° rotation, making it much easier to find side defects such as poor soldering, voids, and insufficient tin. The CNC automatic inspection mode supports fast multi-point batch testing, which greatly improves efficiency for mass production lines. The 550mm×550mm loading platform can hold large PCBs, LED boards, and various electronic components.



The electronics xray bga system features a visual HD navigation window that simplifies operation. Even new users can master basic functions within just two hours of training. Combining ease of use, strong stability, and professional detection performance, the DH-X8 x ray machine pcb is an ideal quality control tool for electronics factories, maintenance centers, and testing laboratories. This practical xray bga machine helps manufacturers reduce defect rates, lower production costs, and maintain consistent product quality.



1.130KV closed X-ray tube, long lifespan and maintenance-free;

2.High-resolution digital flat-panel detector for clear imaging;

3.Laser auto-navigation for fast and accurate positioning;

4.X/Y/Z axis movement control for smooth operation;

5.CNC automatic mode for efficient multi-point batch inspection;

6.±60° tilt angle for comprehensive defect detection;

7.Optional 360° rotation function for flexible observation;

8.Visual HD navigation window for easy operation;

9.Large 550mm×550mm loading platform;

10.Simple operation, usable after only 2 hours of training.







Shenzhen Dinghua Technology Development Co., Ltd. is a national high‑tech enterprise established in 2011, integrating R&D, manufacturing, sales and after‑sales service. We specialize in providing reliable pcb xray machine, pcb x ray machine, BGA rework stations, X‑ray counting equipment, automatic ball planting machines and other SMT peripheral solutions. Our professional inspection systems are widely used in consumer electronics, automotive electronics, semiconductor packaging and PCB manufacturing.



Adhering to the philosophy of "R&D as the foundation, quality as the core, service as the guarantee", we own 78 patents and 97 quality control procedures. Our product line covers entry‑level, middle‑end and high‑end models, ranging from manual to fully automatic configurations. We have two independent subsidiaries: Shenzhen Dinghua Kechuang Automation Co., Ltd. and Shenzhen Dinghua Kechuang Technology Co., Ltd., ensuring stable production capacity and responsive technical support for global customers.
